Shandong Katop Machinery Co.,Ltd.
10 Years
| Ask Lasest Price | |
| Brand Name : | KATOP |
| Model Number : | TT704/TT754 |
| Certification : | CE |
| Price : | 0 |
| Payment Terms : | L/C, T/T |
| Supply Ability : | 300 UNITS per month |
| Delivery Time : | 15 days |
| MODEL | TT704 | TT754 |
| DRIVE TYPE | 4x4 | 4x4 |
| ENGINE | ||
| ENGINE | YUCHAI 498 Turbo | YUCHAI 498 Turbo |
| OIL TANK(L) | 38 | 38 |
| Rated speed (r/min) | 2400 | 2400 |
| ENGINE RATED POWER (Kw) | 51.5 | 55.1 |
| MIN OIL CONSUPTION(g/kw·h) | ≤242 | ≤242 |
| Minimum fuel consumption at full load( L/h) | 10.82 | 11.58 |
| TRANSMASSION | ||
| CLUTCH | 10 inch dry, double-acting clutch | 10 inch dry, double-acting clutch |
| PTO SPPED(rpm) | 540&720 | 540&720 |
| SHAFT | 12F+12R | 12F+12R |
| HYDRUALIC VALVE | 1-Way | 1-Way |
| Three point linkage | ||
| lifting force at 610mm KN | ＞16 | ＞16 |
Technical parameters | ||
| Dimension LxWxH mm | 3579*1830*2130 | 3579*1830*2130 |
| WEIGHT(KG) | 2285 | 2285 |
| WHEEL BASE(mm) | 2016 | 2016 |
| FRONT TREAD(mm) | 1300 | 1300 |
| REAR TREAD(mm) | 1300 | 1300 |
| MIN GROUND CLEARENCE (mm) | 325 | 325 |
| FRONT WHEEL | 8.3-24 | 8.3-24 |
| REAR WHEEL | 14.9-30 | 14.9-30 |
| EXW | 62000 | 63000 |
|
|
